When the Input Voltage to the Circuit Shown in Figure

question 42

Multiple Choice

When the input voltage to the circuit shown in Figure 12-16 is 0 V

• A) the LED is on.
• B) the LED is off.
• C) the drain voltage is +20 V.
• D) the source voltage is +20 V.

---
