A Work Cell Is Required to Make 140 Computerized Diagnostic

question 77

Essay

A work cell is required to make 140 computerized diagnostic assemblies (for installation into hybrid automobiles)each day.The cell currently works an eight hour shift,of which seven hours is available for productive work.These assemblies require five operations.Standard times for these operations are: Operation A,3.0 minutes,B,1.8 minutes,C,2.4 minutes,D,2.5 minutes,and E,1.4 minutes.What is takt time for this cell? How many workers will be needed to achieve this schedule? Use the grid below to construct a work balance chart for this cell.

---

Definitions:

Ratio Scales

Measurement scales that have a true zero point and allow for comparisons of absolute magnitude; examples include height, weight, and duration.

Absolute Zero

The point at which there is a complete absence of heat, theoretically the lowest possible temperature, -273.15°C or 0K.

Quantitative Distinctions

Differences or characteristics that can be measured and expressed numerically, often used in research to classify or analyze data.

Measurement Scale

A system for assigning numbers to objects or events according to a set of rules, illustrating quantities or qualities.
